Smart Link

The graph:smartLinks module generates interactive, rich previews that display contextual information and actions for linked content from supported platforms. Smart Links enhance the user experience by providing instant access to key details and functionality without leaving the current page.

Smart Links retrieve information from third-party apps in real time as the link is rendered, ensuring the displayed data is always up to date.

Smart Link requests are executed in the context of the user. Both Atlassian and the app developer share responsibility for respecting user permissions, ensuring that users can only access data they are authorized to view.

By using the asUser() the user Authentication token will automatically be injected in the communication to the remote system. The App should check that the user has a valid token, and if not, trigger the process to authenticate the user.

Manifest structure

1
2
modules {}
└─ graph:smartLink []
   ├─ key (string) [Mandatory]
   ├─ name (string) [Mandatory]
   ├─ icon (string) [Mandatory]
   ├─ function (string) [Mandatory]
   ├─ domains [string] [Mandatory]
   ├─ subdomains (boolean) [Optional]
   └─ patterns [string] [Mandatory]
function []
├─ key (string) [Mandatory]
└─ handler (string) [Mandatory]

Properties

Manifest example

1
2
modules:
  graph:smartLink:
    - key: sl-test-example-hello-world
      icon: https://static.example-hello-world.com/favicon.ico
      name: sl-test
      function: getEntityByUrlFn
      domains:
        - example-hello-world.com
        - www.example-hello-world.com
      subdomains: true
      patterns:
        - https:\/\/([\w\.-]+\.)?example-hello-world\.com\/([0-9a-zA-Z]{4,128})(?:\/.*)?$
  function:
    - key: getEntityByUrlFn
      handler: index.getHelloWorldEntityByUrl

Supported object types

All Teamwork Graph object types are supported by the Smart Link module.

API Contract

Request

Atlassian will invoke the function specified within the graph:smartLink module when it matches one or more domains as well as at least one pattern. If there are multiple links on a given page for the same App that match, these will all be provided in one single request.

1
2
request {}
├─ type (string) [Mandatory]
└─ urls (Array of string) [Mandatory]

Properties

Example:

Below is a request to resolve two links.

1
2
{
  "type": "resolve";
  "payload": {
    "urls": ["https://www.example-link.com/example1","https://www.example-link.com/example2"];
}

Response

1
2
response {}
└─ entities [] (Array of EntityResult) [Mandatory]
    ├─ identifier {} (Identifier) [Mandatory]
    │   └─ url (String) [Mandatory]
    ├─ meta {} (Meta) [Mandatory]
    │   ├─ access (String) [Mandatory]
    │   └─ visibility (String) [Mandatory]
    └─ entity [] (Array of Object) [Optional]

Properties

Example:

1
2
{
  "entities": [
    {
      "identifier": {
        "url": "https://www.example-link.com/example1"
      },
      "meta": {
        "access": "granted",
        "visibility": "restricted"
      },
      "entity": {
        "id" : "my-document",
        "updateSequenceNumber" : 123,
        "displayName" : "My Document",
        "url" : "https://document.com",
        "thumbnail" : {
          "externalUrl" : "https://document-thumbnail.com"
        },
        "createdAt" : "2024-04-16T09:01:32+00:00",
        "atlassian:document" : {
          "type" : {
            "category" : "document",
            "iconUrl" : "http://icon.com"
          },
          "content" : {
            "mimeType" : "text/plain",
            "text" : "Really large content here..."
          },
          "byteSize" : 456,
          "labels" : [ "label1", "label2" ],
          "reactions" : [ {
            "type" : "LIKE",
            "total" : 1
          } ],
          "exportLinks" : [ {
            "mimeType" : "text/plain",
            "url" : "http://localhost"
          } ]
        }
      }
    },
    {
      "identifier": {
        "url": "https://www.example-link.com/example2"
      },
      "meta": {
        "access": "forbidden",
        "visibility": "restricted"
      }
    }
  ]
}
