This module now has support for UI Kit 2 (preview) for faster user experiences and to access additional React features.

For more information on all the supported modules, see the Supported products and their modules section.

Confluence content byline item

The confluence:contentBylineItem module adds an entry to the content byline section, which is the part of the content under the title that includes metadata about contributors and more. The title, icon, and tooltip of the module render together as a list item.

See the ContentBylineItem component documentation for an example.

Example of a Content byline item

When adding the confluence:contentBylineItem module to your app, use it along with the InlineDialog UI kit component.

Properties

PropertyTypeRequiredDescription
key

string

Yes

A key for the module, which other modules can refer to. Must be unique within the manifest.

Regex: ^[a-zA-Z0-9_-]+$

functionstringThe content byline item module requires either a function for usage with the UI kit, or a resource when building with custom UI.A reference to the function module that defines the content byline item.
resourcestringA reference to the static resources entry that your content byline item wants to display. See resources for more details.
render'native'Yes for UI Kit 2Indicates if the module is a UI Kit 2 module.
resolver{ function: string } or
{ endpoint: string }
Yes

Set the function property if you are using a hosted function module for your resolver.

Set the endpoint property if you are using Forge remote to integrate with a remote backend.

Can only be set if the module is using the resource property.

viewportSize'small', 'medium' or 'large'The display size of resource. Can only be set if the module is using the resource property. Remove this property to enable automatic resizing of the module.
titlestringYesThe title of the content byline item, which is displayed as a list item.
iconstring

The icon displayed next to the title.


For custom UI and UI kit apps, the icon property accepts a relative path from a declared resource. Alternatively, you can also use an absolute URL to a self-hosted icon. See Icons for more information.

If no icon is provided, or if there's an issue preventing the icon from loading, a generic app icon will be displayed.

tooltipstringThe tooltip of the content byline item, which is displayed on hover.
descriptionstringThe description of the content byline item.
displayConditionsobjectThe object that defines whether or not a module is displayed in the UI of the app. See display conditions.
dynamicProperties{ function: string }Contains a function property, which references the function module that defines the configuration of resource. See Dynamic properties for more details.
keyboardShortcutobjectThe object that defines a keyboard shortcut to trigger this module. See keyboard shortcuts.

Dynamic properties

Dynamic properties are used to dynamically update the title, icon, or tooltip properties of the confluence:contentBylineItem module. If provided in the manifest.yml file, Confluence attempts to retrieve the dynamic properties on the initial render of the app. To do this, the dynamicProperties handler function of the app is called. When the content byline item is clicked, the app renders in a dialog, where it can perform business logic updates. After the dialog is closed, the handler function is again called to retrieve updates, and then update the title, icon, or tooltip.

The app's handler function is passed two arguments: payload and context. The payload object has the following structure:

1
2
interface Payload {
  // The cloudId for your site
  cloudId: string;
  // A unique id for this instance of this component in the content
  localId: string;
  extension: {
    // The module type included in the manifest.yml file.
    // In this case, it is the "confluence:contentBylineItem" module.
    type: string;
    content: {
      // The unique identifier of the Confluence content
      id: string;
      // The type of Confluence content on which the invocation has occurred
      type: 'page' | 'blogpost' | 'space';
    };
    space: {
      // The id of the originating invocation space
      id: string;
      // The key of the originating invocation space
      key: string;
    }
  };
}

The context object has the following structure:

1
2
interface Context {
  principal: {
    accountId: string;
  };
  installContext: string;
}

The handler function should return (or resolve with) a plain old JavaScript object with a title, icon, and tooltip as keys. These optional keys are only sent if their respective values require updating. Failure to provide a key would default to the last used value or the original values defined within the manifest.yml file.

Below is an example of a handler function returning a returned object:

1
2
function handlerFunction(contextPayload) {
  return {
    "title": "Updated title",
    "icon": "https://mydomain.com/my-icon.png",
    "tooltip": "Updated Tooltip"
  };
}

When you use an icon in your dynamic properties, its source URL is subject to a permission check.

For an example of adding source URL permissions for your icon property, see External Permissions.

Bundled resources in the following formats are allowed by default:

  • resource:<resource key>;<relative path to resource>
  • data:image URIs

See Icons for more information about bundling icons as a resource.

When the source URL does not have the appropriate permissions, the dynamic properties are not loaded. The default configuration is used instead.

Check out the Page approver app as an example of an app that updates the title and tooltip on change, and prepopulates a default icon that's missing from the manifest.yml file.

Extension context

Custom UI

PropertyTypeDescription
typestringThe type of the module.

UI kit

PropertyTypeDescription
typestringThe type of the module.
